First , the methods of use and quantitative methods:
1, the plug needle and venting needle were inserted into the vial.
2, the catheter from the plug needle connected to the feeder connector. First adjust the screw gauge screw in the 1ml or so position, pull the wrench, after playing the liquid and then adjust the adjustment screw to the required dose of the location
(Scale scale to align the nut bottom plane). Tighten the locking nut near the locating nut.
3, continuous playing several times, until the vaccine, and then loaded with the needle can be used.
4, the dose adjustment range of 0-2ml.
Second, disinfection methods:
1, even after the use of the device, according to counterclockwise oblique handle.
2, will remove the parts (except the handle) into the water to boil for 10 minutes.
3, re-installed parts and handle, hit the water inside the injector.
Third, maintenance methods:
1, even when the device is not thoroughly washed (with distilled water or water) the various parts, so as not to liquid residue.
2, with medical silicone oil or paraffin coated steering valve and "O" type circle, with a clean cloth to dry parts after assembly package, anti-dry place to save.
1, even if the device is placed for a long time, there may be no drug phenomenon, which is not even the quality of the device, but because of the adjustment or use of liquid residue caused by suction valve and connector
There is adhesion phenomenon, just use the needle through the joint hole on the hole gently to the top of the suction valve can be. If you still do not smoke may be the release valve and the main body of the phenomenon of adhesion. Remove the locking lever and release the valve
The subject is separated and then reassembled.
2, cleaning or replacement parts of the solid must be tightened to prevent leakage.
Five, with accessories:
1, a bottle of a needle 2, a gas valve 1 3, a hose 4, the steering valve spring 2 5, 2 steering valve 6, 2 seals
How to choose a suitable continuous veterinary syringe
1. Upon the volume injecting every time
Each dose-----------0.05-0.5ml. choose 0.3ml/0.5ml
----------- 0.1-1ml, choose 1ml
-----------0.2-2ml. choose 2ml
-----------1-5ml, choose 5ml
2. Upon the user------for vaccine injection
User---------if for chicken, duck, rabbit, rare birds. Choose 0.3ml/0.5ml/1ml
---------if for piglet, calve , lamb . Choose 1ml
---------if for pig, cow, goat(25kg or more), choose 2ml
---------if for pig , cow, goat (adult). Choose 2ml/5ml
3. Upon personal preferences and habits
Choose whatever you like
