Industrial Centrifugal Exhaust Fan/Chicken Poultry House Ventilation Fan/Greenhouse Ventilation Cooling Pad System
1, Frame: frames are made of hot dip galvanized sheet, frame thickness 1.0mm,. Galvanizing layer 180g/square meters.
2, Blade: 6 pieces, material 430/304 stainless steel.
3, Impeller: casting aluminum alloy impeller.
4,bearing of impeller: permanently sealed bearing, size 633313.
5, Collector: galvanized sheet, thickness 1.0mm.
6, Blade tip clearance: 25mm, mirror face.
7, Protecting mesh : plastic sprayed steel wire, thickness 2.8mm.
8, Electrical motor: aluminum alloy frame motor, 380V/220/415V, 1.1KW/0.75KW(1.5HP/1HP), 50HZ/60HZ, 3PH/Single Phase, 4-pole speed, 1410r/m, IP55, class F, efficiency 90%, top/foot mounted,
9, Motor bearing: cast iron.
10,Belt: B-belt and A-belt (Made-in-China and Japan brand Mitsuboshi).
11, Shutters: galvanized board, 0.8 mm thickness while the middle piece thickness 1.0mm. Galvanizing layer, 120g/square meter.
12, Opening system: centrifugal push-push open device.
13, Rivets: aluminum alloy and stainless steel rivets.
1. Provide sample to customer
2. Help customer design according to requirements
3. Provide best price
1. Help booking container and arrange well logistics
2. Free charge loading container
1. Oversea service provide
2.10 years warranty
